Get $700 manufacture rebate or FREE VistaPure V3000 with purchase of New SciCan Bravo G4 Class B Autoclave and Statim G4 5000.
About the BRAVO G4 The BRAVO G4 Chamber Autoclave is a Class B sterilizer designed for speed, capacity, safety, and efficiency. Its cutting-edge sterilization technology incorporates both pre-sterilization vacuum to improve steam penetration and post-sterilization vacuum to improve drying. Includes one customizable program and five standard programs.
Features and Benefits of the Bravo G4 Autoclave:
- Save Time - Reprocess instruments quickly with fast sterilization times. The Bravo G4 17L 240V has an unwrapped sterilization time of only 27 minutes, including dry time!
- Ensure instruments are DRY with closed door drying and post-vacuum technology
- Efficient capacity - the BRAVO G4 17L can sterilize 3 full-size cassettes or up to 20 pouches. The BRAVO 22L can sterilize 3 oral surgery cassettes or up to 25 pouches.
- SciCan’s G4 sterilizers can connect and send information via wifi - send cycle data and maintenance notifications to your smart devices or phone
- Digital Cycle Data Reporting via USB port
- Gentle: Fresh water is used in every cycle, reducing the buildup
of oils and debris.
- Versatile - The BRAVO G4 offers numerous filling and draining options, including manual top and front filling, and automatic filling and draining through ports in the back.
About the SciCan G4 5000 STATIM's unmatched speed and dependability have made STATIM the world's best-selling autoclave. And its patented gentle technology has made STATIM the world's favorite. The STATIM G4 will offer you a level of interactivity never seen before. The STATIM G4, through its LCD touch screen control and STATIM Live networking capability, has been designed to provide you with unprecedented ease of use and puts the user in total control.
Features and Benefits of the Statim G4 5000:
- Immediate Steam Generation - Unlike conventional autoclaves that need to heat an entire reservoir of water, STATIM uses only a small, specific amount of water required for each cycle. Water is introduced into a heating device referred to as a steam generator, rapidly heated and converted to steam in mere seconds.
- Air Removal - Using PPPD technology and our patented steam injection process“ air is automatically forced out of the sterilization chamber
- Cassette System - The thin stainless steel walls of STATIM™s fully-removable cassette, (or sterilization chamber) allow for rapid heating and cooling of the chamber. As a result, STATIM meets the conditions for sterilization and drying in a fraction of the time required by a conventional autoclave
- Drying Technology - The STATIM 2000 and 5000 have each been designed to provide you with a complete solution: rapid sterilization balanced by rapid drying
- Touch - A large 3.5†high-resolution touchscreen offers a vivid display of messages, current cycle information and customizable colours all with extraordinary clarity. Fully adjustable contrast levels let you optimize the screen to the lighting in your steri-centre
- Connect - Through your networked portal, you can view not only your STATIMs current operations in real time, you can also access cycle history, printing and validation information, and also sterilization records. Capable of sending emails with cycle information errors directly to your dealer, your STATIM G4 will let qualified technicians know when service is imminent
- Protect - Patient safety relies on attention to detail. The STATIM G4 supports verifiable processes that are PIN protected with user-defined IDs so that staff members can be required to authorize a cycle. This encourages extra attention to process and creates a safer environment for both staff and patients
- Collect - An undocumented sterilization cycle might as well not have been performed. With each cycle, information must be stored to protect your office and your patient. The integrated DataLogger stores all cycle information for the lifetime of the unit, which is accessible through multiple channels such as: a USB port for manual retrieval; an Ethernet connection for web based archiving or desktop printing; or a RS232 port for an external printer option.
Learn more about the VistaPure V3000
Bravo G4 Technical Specifications
- Specs will vary based on Bravo G4 model - 17L or 22L, available in 120V and 240V
Description
|
Sterilization
Temperature
|
Cycle Time*
|
Maximum Load
|
Total Cycle Time* (includes drying)
|
Solid Unwrapped
|
270° F
|
4 min
|
16.53 lbs
|
42 min
|
Solid Wrapped
|
270° F
|
4 min
|
16.53 lbs
|
52 min
|
Hollow Unwrapped
|
270° F
|
4 min
|
16.53 lbs
|
63 min
|
Hollow Wrapped
|
270° F
|
4 min
|
16.53 lbs
|
73 min
|
Rubber & Plastic
|
250° F
|
20 min
|
16.53 lbs
|
89 min
|
*Cycle time varies based on loads
Statim 5000 G4 Technical Specifications
- Controls: Automatic
- Dimensions (L x W x H): 23.6” x 16.1” x 7.5”
- Cassette internal dimensions: 15” x 7” x 3”
- Cassettes: 1
- Voltage: 115V, 50/60 Hz, 15A / 1450 W
- Weight without water: 73 lbs (33 kg)
Description
|
Sterilization Temperature
|
Sterilization Time
|
Total Cycle Time
|
Unwrapped Instruments
|
270° F
|
3.5 min
|
9 min
|
Wrapped Instruments
|
270° F
|
6 min
|
17.5 min
|
Rubber, plastic
|
250° F
|
35 min
|
45 min
|
Heavy Duty Unwrapped / Air Drying
|
270° F
|
6 min
|
12 min
|
|
|
|
|
|
|
|
